Khoom Description
Lub 8 tuj diesel nqa tsheb tsim rau kev ua haujlwm siab, lub cav Japanese ua kom zoo thiab ua haujlwm tau zoo.
Lub cav nyob rau hauv 8 tuj diesel forklift yog tsim los ua ob qho tib si ruaj thiab siv tau zoo. Nws yog plaub-stroke diesel cav uas siv cov tshuab txhaj tshuaj ncaj qha los ua kom muaj roj ntau tshaj plaws thiab txo qis emissions. Qhov no txhais tau hais tias 8 tuj diesel forklift tsis yog tsuas yog txhim khu kev qha thiab muaj zog, tab sis kuj yog ib puag ncig zoo.
Lub tshuab hydraulic ntawm 8 tuj diesel forklift yog tsim los ua kom pom kev ua haujlwm zoo nyob rau hauv ntau yam kev ua haujlwm. Lub kaw lus suav nrog lub twj tso kua mis hydraulic uas xa cov roj mus rau ntau lub tog raj kheej thiab cov li qub, uas tswj cov dej ntws thiab cov kev taw qhia ntawm cov roj. Ib qho ntawm qhov zoo tshaj plaws ntawm hydraulic system ntawm 8 tuj diesel forklift yog nws lub peev xwm los nqa cov khoom hnyav sai thiab nyab xeeb.
Ntxiv rau nws lub cav txhim khu kev qha, 8 tuj diesel forklift tseem muaj ntau yam kev nyab xeeb siab heev, suav nrog ntau yam kev xaiv pom, muaj kev ceeb toom dav dav, thiab cov tshuab braking siab heev kom cov neeg ua haujlwm muaj kev nyab xeeb thiab nyab xeeb thaum ua haujlwm.
Hauv cov ntsiab lus, 8 tuj diesel forklift nrog Japanese cav yog lub tshuab muaj peev xwm uas muaj cov yam ntxwv tshwj xeeb rau kev siv nqa hnyav.
Cov khoom parameter
| General | Qauv | FD50 | FD60 | FD70 | FD80 | |||
| Hom fais fab | Diesel | Diesel | Diesel | Diesel | ||||
| Rated Peev Xwm | kg | 5000 | 6000 | 7000 | 8000 | |||
| Load Center | mm | 600 | 600 | 600 | 600 | |||
| Yam ntxwv & Dimension | Nqa Qhov siab | mm | 3000 | 3000 | 3000 | 3000 | ||
| Fork Loj | L×W×T | mm | 1220×150×60 | 1220×150×60 | 1220×150×70 | 1220×150×70 | ||
| Mast Tilt Angle | F/R | Deg | 6 degree / 12 degree | 6 degree / 12 degree | 6 degree / 12 degree | 6 degree / 12 degree | ||
| Fork Overhang (Lub log qhov chaw rau nkhaus ntsej muag) | mm | 590 | 590 | 595 | 595 | |||
| Av Clearance (hauv qab ntawm mast) | mm | 200 | 200 | 200 | 200 | |||
| Zuag qhia tag nrho Dimension | Ntev mus rau lub ntsej muag ntawm rab rawg (tsis muaj diav rawg) | mm | 3440 | 3440 | 3565 | 3565 | ||
| Dav dav | mm | 2010 | 2010 | 2010 | 2010 | |||
| Mast Lowered Height | mm | 2500 | 2500 | 2500 | 2500 | |||
| Mast Extended Qhov siab (nrog backrest) | mm | 4415 | 4415 | 4415 | 4415 | |||
| Overhead Guard Qhov siab | mm | 2430 | 2430 | 2430 | 2430 | |||
| Tig Radius (sab nraum) | mm | 3250 | 3250 | 3350 | 3350 | |||
| Kev ua tau zoo | Ceev | Mus ncig teb chaws (Full load) | km/h | 30 | 30 | 30 | 28 | |
| Lifting (tag nrho load) | mm/s | 500 | 500 | 460 | 430 | |||
| Max.Gradeability | % | 20 | 20 | 20 | 20 | |||
| Chassis | Lub log | Pem hauv ntej | mm | 8. 25-15-14PR | 8. 25-15-14PR | 8. 25-15-14PR | 8. 25-15-18PR | |
| Qab | mm | 8. 25-15-14PR | 8. 25-15-14PR | 8. 25-15-14PR | 8. 25-15-18PR | |||
| Wheelbase | mm | 2250 | 2250 | 2250 | 2250 | |||
| Tus kheej hnyav | kg | 8150 | 8750 | 9750 | 10350 | |||
Cov khoom pov thawj
tuam txhab kev taw qhia
Cov khoom siv
FAQ
Q: Yuav ua li cas tus neeg teb xov tooj forklift ua kom muaj txiaj ntsig ntawm 8-tuj diesel forklift?
Q: Dab tsi yog kev ceev faj txog kev nyab xeeb uas yuav tsum tau ua thaum ua haujlwm ntawm 8-tuj diesel forklift?
Q: Dab tsi yog qhov zoo ntawm kev siv 8-tuj diesel forklift nyob rau hauv qhov chaw cia khoom?
