Cov khoom tshwm
Vim li cas thiaj xaiv peb lub tuam txhab?
LTMG sawv ua tus tsim khoom lag luam tseem ceeb ntawm cov cuab yeej siv khoom, suav nrog forklifts, ncav cuag stackers, thiab ntau yam kev daws teeb meem. Kev khav theeb ob xyoo caum-ntev nyob rau hauv lub sector, LTMG tau txais kev qhuas rau kev tsim khoom zoo tshaj plaws, cov cuab yeej siv tau zoo raws li qhov dav ntawm daim ntawv thov scenarios. Peb cov kev pabcuam suav nrog cov thev naus laus zis thev naus laus zis thiab tau tsim kho kom tiv taus qhov nyuaj ntawm kev ua haujlwm nyuaj. Tsav los ntawm kev cog lus rau kev tsim kho tshiab, peb muab peb cov neeg siv khoom nrog cov kev daws teeb meem uas tsav kev ua tau zoo, tsim khoom, thiab txhim kho kev nyab xeeb hauv lawv txoj haujlwm. LTMG yog unwavering nyob rau hauv nws txoj kev mob siab rau cov neeg siv khoom txaus siab, tsis tu ncua siv zog xa cov kev pabcuam hwm thiab kev txhawb nqa thoob ntiaj teb.
Khoom Parameters
|
specification |
||||||
|
General |
Tsim |
LTMG |
||||
|
Qauv |
LTR 150 / LTR 200 |
|||||
|
Hom roj |
diesel roj |
|||||
|
Rated peev |
kg |
15000/20000 |
||||
|
Chaw thau khoom |
mm |
800 |
||||
|
Qhov ntev |
Nqa qhov siab |
mm |
3000 |
|||
|
Dawb nqa qhov siab |
mm |
100 |
||||
|
Fork loj |
mm |
2400×200×100 |
||||
|
Txee Side Shift Distance |
Sab laug / Sab xis |
mm |
205/205 |
|||
|
Fork spacing adjustment |
Min./Max. |
mm |
280/2320 |
|||
|
Mast qaij lub kaum sab xis |
Ua ntej / Tom qab |
deg |
8/10 |
|||
|
Pem hauv ntej overhang |
mm |
1380 |
||||
|
Zuag qhia tag nrho dismensions |
Ntev mus rau lub ntsej muag ntawm rab rawg |
mm |
9700 |
|||
|
dav dav |
mm |
3040 |
||||
|
Mast txo qhov siab |
mm |
3350 |
||||
|
Mast ncua qhov siab |
mm |
4850 |
||||
|
Safety khib qhov siab |
mm |
3700 |
||||
|
Hloov lub vojvoog |
mm |
7800 |
||||
|
Min.right angle aisle dav |
mm |
8500 |
||||
|
Kev ua tau zoo |
noload / puv load |
Kev ceev ceev |
Km/h |
30/28 |
||
|
Lifting ceev |
mm/sec |
320/270 |
||||
|
Max.qeb muaj peev xwm |
º |
Ntau dua lossis sib npaug li 21 |
||||
|
Max.Pull force (tag nrho load) |
KN |
180 |
||||
|
Tus kheej hnyav |
kg |
24200/26000 |
||||
|
Chassis |
Log tsheb |
Pem hauv ntej |
2 × 23 5-25-32PR |
|||
|
Qab |
2 × 23 5-25-24PR |
|||||
|
Tread |
Pem hauv ntej |
mm |
2380 |
|||
|
Qab |
mm |
2380 |
||||
|
Wheelbase |
mm |
3710 |
||||
|
Min.Ground clearance (tsis muaj load / tag nrho load) |
Mast |
mm |
450/400 |
|||
|
Ncej |
mm |
500/450 |
||||
|
Fais fab Unit thiab Control |
Roj teeb |
V/AH |
24/100×2 |
|||
|
Cav |
Qauv |
6CTA8 3-C240 |
||||
|
Tsim |
Cummins |
|||||
|
Rated tso zis |
Kw/rpm |
179/2200 |
||||
|
Rated torque |
Nm/rpm |
1028/1500 |
||||
|
Roj tank peev xwm |
L |
220 |
||||
|
Kev sib kis |
Hom |
Hydraulic |
||||
|
Hloov |
Pem hauv ntej / nram qab |
2/1 |
||||
Nrog technology innovation, peb cov khoom configuration thiab tsis yuav hloov mus ntxiv yam tsis muaj ntawv ceeb toom; yog tias muaj kev tsis ntseeg;
qhov kev lees paub tshwj xeeb ntawm peb cov kev muag khoom thoob ntiaj teb yuav tsum yeej.
xaiv tau
FAQ
Q: 1. Vim li cas thiaj xaiv peb?
Q: 2. Cov khoom lag luam ntawm peb lub Hoobkas yog dab tsi?
Q: 3. Cov nqe lus them nqi dab tsi peb tuaj yeem lees txais?
Q: 4. Peb muaj daim ntawv pov thawj dab tsi?
Q: 5.Yuav ua li cas txog peb lub sijhawm khoom xa tuaj?
muaj nyob rau hauv Tshuag thiab tuaj yeem xa tuaj sai. Tab sis cov khoom customized yuav siv sij hawm ntau dua, nyob ntawm seb koj xav tau kev txiav txim.
Q: 6. Peb puas tuaj yeem muab kev pabcuam OEM?
Cim npe nrov: Tuam Tshoj 20 tuj hnyav luag hauj lwm off-txoj kev forklift kev muag khoom, Tuam Tshoj 20 tuj hnyav off-txoj kev forklift manufacturers
