Khoom Description
Lub tshuab hluav taws xob ntau txoj kev sib tw forklift tsheb tau ntim nrog cov yam ntxwv tshwj xeeb thiab khav theeb kev ua tau zoo, lub forklift tsheb no yog tsim los txhim kho cov khoom tsim tau thiab kev ua haujlwm zoo thaum ua kom cov neeg ua haujlwm zoo siab.
Hluav taws xob fais fab Steering (EPS) system: EPS system ua ke nrog ib qho yooj yim-hloov mechanism los hloov kev tsav tsheb tsis yooj yim. Qhov kev teeb tsa kev tswj hwm tsis zoo no tsuas yog ua kom yooj yim rau kev ua haujlwm tab sis kuj txo cov neeg ua haujlwm qaug zog, ua kom nrawm thiab meej maneuvering nyob rau hauv qhov nyuaj tshaj plaws.
Nruab nrog Shimadzu hom iav twj tso kua mis thiab lub buffering hydraulic lub tog raj kheej, lub forklift multidirectional muab tshwj xeeb lifting thiab txo lub peev xwm. Cov txheej txheem hydraulic siab ua kom muaj kev sib tw thiab tswj tau, txo qhov kev pheej hmoo ntawm cov khoom puas tsuaj thiab ua kom muaj kev nyab xeeb thaum ua haujlwm.
Tsim los ntawm lub npe nrov USA Curtis maub los, lub tsheb forklift no muaj kev tswj xyuas meej rau kev ua haujlwm zoo dua. Lub Curtis maub los xyuas kom meej acceleration thiab deceleration, tso cai rau cov neeg tsav tsheb mus rau qhov chaw nruj nrog kev yooj yim thiab kev ntseeg siab. Nws cov qauv tsim ntse optimizes lub zog efficiency, ua rau lub neej ntev roj teeb thiab txo cov nqi khiav lag luam.
Ntxiv nrog rau nws qhov kev ua tau zoo tshaj plaws, ntau txoj kev mus txog lub tsheb thauj khoom tseem ceeb rau tus neeg teb xov tooj kev nplij siab. Featuring ib tug zaum-hom tsim, nws muab ib tug ntau ergonomic thiab xis chaw ua hauj lwm ib puag ncig rau cov neeg ua hauj lwm thaum lub sij hawm ncua kev hloov. Lub rooj zaum tsim tau zoo, ua ke nrog cov kev tswj tau yooj yim thiab cov legroom txaus, pab txhim kho cov khoom tsim tau los ntawm kev txo cov neeg ua haujlwm qaug zog thiab txhawb kev ua kom pom tseeb dua.
Lub forklift ntau yam no pom ntau daim ntawv thov thoob plaws ntau yam kev lag luam. Los ntawm cov tsev khaws khoom loj thiab cov chaw xa khoom mus rau cov chaw tsim khoom thiab kev lag luam logistics, nws ua tau zoo ntawm kev tuav ntau yam ntawm cov khoom thauj, suav nrog cov khoom ntev thiab loj. Nws muaj peev xwm ua tau ntau txoj kev tso cai rau kev siv zog ua haujlwm hauv qhov chaw nruj thiab nqaim aisles, ua rau nws yog qhov kev xaiv zoo tshaj plaws rau kev ua kom muaj peev xwm cia siab tshaj plaws thiab txhim kho kev ua haujlwm tag nrho.
LTMG multi-directional forklift sib txuas cov yam ntxwv siab heev thiab ergonomic tsim los muab cov khoom siv tsis sib xws. Nrog nws EPS thiab ib-hloov kev tsav tsheb tswj kev tswj, Shimadzu hydraulic Cheebtsam, precision Curtis maub los, thiab tus neeg tsav tsheb-tsim qauv, lub forklift tsheb no lav kev ua tau zoo, txhim kho cov khoom tsim tau, thiab cov neeg ua haujlwm tsis sib haum xeeb. Kev paub txog qib tshiab ntawm kev ua tau zoo hauv koj cov khoom siv ua haujlwm nrog lub tsheb forklift tshwj xeeb no.
Cov khoom parameter
|
Hom |
LTMG |
LTMG |
|
|
Qauv |
FRB 30 M |
FWB 40 M |
|
|
Hom fais fab |
Roj teeb |
Roj teeb |
|
|
Hom kev ua haujlwm |
Zaum |
Zaum |
|
|
Kev pabcuam hnyav (nrog rau roj teeb) |
kg |
5480 |
7750 |
|
Rated Peev Xwm |
Q (kg) |
3000 |
4000 |
|
Load Center |
C (mm) |
600 |
600 |
|
Nqa qhov siab |
h3 (mm) |
3000 |
3000 |
|
Forks loj |
l/e/s (mm) |
1200/150/50 |
1200/150/50 |
|
Pem hauv ntej Overhang |
x (mm) |
305 |
318 |
|
Lub vojvoog tig |
Qhov (mm) |
2000 |
2770 |
|
Max. nce kev muaj peev xwm |
% (tanθ) |
8/10 |
8/10 |
|
Tsav ceev (load / unload) |
km/h |
7.8/9 |
7.8/9 |
|
Lifting ceev (load / unload) |
mm/s |
170/220 |
170/220 |
|
Tsawg ceev (load / unload) |
mm/s |
130 |
130 |
Cov khoom qhia meej
Cov khoom siv
cov khoom muaj feem xyuam
FAQ
Q: Dab tsi yog ib qho hluav taws xob ntau qhov taw qhia counterbalanced forklift tsheb?
Q: Cov txiaj ntsig ntawm forklift tsheb yog dab tsi?
Q: Cov ntaub ntawv dab tsi tuaj yeem nqa tau nrog lub tshuab hluav taws xob ntau qhov kev taw qhia counterbalanced forklift?
Q: Yuav ua li cas yog ib qho hluav taws xob multi-directional counterbalanced forklift piv rau lwm hom forklifts?
