Khoom Description
1. Ob Chav Scissor Deep Reach Forks:Qhov kev tsim ob npaug tso cai rau cov diav rawg txuas mus rau pem hauv ntej thiab rov qab, muab ntau yam peev xwm ncav cuag. Cov yam ntxwv no ua rau muaj txiaj ntsig zoo ntawm cov khoom lag luam hauv cov khoom sib sib zog nqus racking thiab ua kom muaj qhov ceev ceev.
2. Extended Reach Distance:Nrog rau qhov kev ncua deb ntawm 1200 millimeters, qhov kev sib sib zog nqus ncav cuag lub tsheb thauj khoom no tuaj yeem nkag mus rau pallets nyob tob hauv qhov system racking. Qhov siab tshaj plaws ncav cuag qhov ntev mus txog 1500 millimeters, kom ntseeg tau tias qhov kev rov qab thiab khaws cov khoom hauv qhov chaw nkag tsis tau tshaj plaws.
3. Tag Nrho AC (Alternating Tam sim no) System:Nruab nrog tag nrho AC system, lub tsheb ncav cuag no muaj zog acceleration, du ua hauj lwm, thiab meej tswj. AC thev naus laus zis kuj ua kom muaj zog ua haujlwm zoo, txo qis kev siv hluav taws xob tag nrho.
4. Compact Design, Lub teeb yuag:Qhov ob qhov tob ncav cuag forklift nta cov qauv tsim, ua rau nws haum rau qhov nqaim aisles thiab qhov chaw kaw. Txawm hais tias nws me me hneev taw, nws muaj peev xwm thauj khoom siab thiab ruaj khov zoo heev. Tsis tas li ntawd, kev tsim kho lub teeb ua rau nws yooj yim rau kev tswj hwm thiab txo qhov kev pheej hmoo ntawm kev puas tsuaj rau cov plag tsev lossis cov racking.
5. Kev tu-dawb ua haujlwm:Lub tsheb sib sib zog nqus ncav cuag ob npaug yog tsim los ua kom tsis muaj kev saib xyuas zoo, txo qis sijhawm thiab cov nqi khiav haujlwm. Nws suav nrog cov thev naus laus zis thiab cov khoom siv, xws li brushless motors thiab sealed bearings, kom txo tau qhov kev xav tau ntawm kev saib xyuas tsis tu ncua thiab ua kom muaj txiaj ntsig zoo.
6. Carbon Txhuam-dawb tsim:Nrog rau cov pa roj carbon txhuam tsis muaj qhov system, qhov no ncav cuag lub tsheb tshem tawm qhov xav tau ntawm kev hloov txhuam tsis tu ncua. Qhov no tsis yog tsuas yog txuag lub sijhawm thiab nyiaj txiag xwb tab sis kuj tseem ua rau lub chaw ua haujlwm huv huv los ntawm kev txo cov pa paug.
7. Ergonomic Controls thiab Cabin Zoo:Lub tsheb sib sib zog nqus ncav cuag tau nruab nrog cov neeg siv kev tswj hwm zoo thiab tus neeg tsav tsheb xis nyob los txhim kho cov khoom tsim tau thiab cov neeg siv kev txaus siab. Tus tsim ergonomic txo cov neeg ua haujlwm qaug zog thiab tso cai rau kev ua haujlwm zoo, ua kom muaj kev ua haujlwm zoo thiab nyab xeeb.
8. Cov yam ntxwv ntawm kev nyab xeeb ntse:Lub tsheb thauj khoom no suav nrog cov yam ntxwv muaj kev nyab xeeb ntse los tiv thaiv tus neeg teb xov tooj thiab ib puag ncig ib puag ncig. Cov yam ntxwv no yuav suav nrog kev sib tsoo sensors, qhov siab txwv qhov siab, tsis siv neeg ceev txo hauv cov ces kaum, thiab khawm nres thaum muaj xwm ceev, thiab lwm yam.
9. Advanced roj teeb Technology:Nws siv lub roj teeb thev naus laus zis thev naus laus zis, ua kom cov sijhawm ua haujlwm ntev dua thiab txo qhov kev xav tau ntau zaus. Lub roj teeb tswj system saib xyuas lub roj teeb qhov kev ua tau zoo thiab muab cov ntaub ntawv ntawm lub sijhawm tiag tiag rau tus neeg teb xov tooj, ua kom lub roj teeb zoo dua qub thiab ua kom lub sijhawm ua haujlwm ntev.
10. Customizable Options:Txhawm rau ua raws li cov kev xav tau tshwj xeeb, lub tsheb sib sib zog nqus ncav cuag muaj cov kev xaiv kho tau. Cov no tuaj yeem suav nrog qhov ntev ntawm rab rawg sib txawv, cov khoom tshwj xeeb txuas, kev tswj hwm qib siab, thiab cov yam ntxwv ntxiv kev nyab xeeb. Qhov kev ua tau zoo no tso cai rau cov neeg siv los kho cov tsheb thauj mus los rau lawv cov kev xav tau tshwj xeeb.
Ob chav tob ncav cuag Truck Specification
|
Qauv |
|
FRB 20 |
|
Hom fais fab |
|
hluav taws xob |
|
Hom kev ua haujlwm |
|
sawv hom |
|
Muaj peev xwm |
Q (kg) |
1500 |
|
Chaw thau khoom |
C (mm) |
500 |
|
Pem hauv ntej overhang |
X (mm) |
173 |
|
Wheelbase |
Y (mm) |
1435 |
|
Mus txog deb |
I4 (mm) |
600 |
|
hnyav |
kg |
1900 |
|
Lub log hom |
|
PU tawv log |
|
Tsav Tsheb |
Ø xw (mm) |
230*75 |
|
pem hauv ntej log |
Ø xw (mm) |
210*85 |
|
Tsheb log |
Ø xw (mm) |
150*50 |
|
Log tread: Pem hauv ntej |
b10 (mm) |
735 |
|
Log tread: rear |
b11 (mm) |
955 |
|
diav rawg txo |
|
1840 |
|
Max Lifting Qhov siab |
h3 (mm) |
2500 |
|
Max. qhov siab |
h4 (mm) |
3416 |
|
Fork qhov siab thaum gantry retracted |
H13 (mm) |
35 |
|
Mast / carriage qaij lub kaum sab xis (pem hauv ntej / nram qab) |
0 |
3/5 |
|
Zuag qhia tag nrho qhov siab (nrog diav rawg) Zuag qhia tag nrho ntev (tsis muaj diav rawg) |
I2 (mm) |
1834/2276 |
|
Dav dav |
b1 (mm) |
1034 |
|
Fork dimension |
s/e/l (mm) |
35/100/1070 |
|
diav rawg |
b5 (mm) |
210-680 |
|
Min av clearance |
m2 (mm) |
70 |
|
Min.stacking.aisle.1000*1200pall |
Ast (mm) |
2715 |
|
Min.stacking.aisle.1000*1200pall |
Ast (mm) |
3116 |
|
Hloov lub vojvoog |
Qhov (mm) |
1752/2153 |
|
Max mus ncig ceev) (Tsis muaj load / puv) |
km/h |
5/4 |
|
Lifting ceev (Tsis muaj load / puv) |
m/s |
0.112/0.092 |
|
Lowered ceev (Tsis muaj load / puv) |
m/s |
0.094/0.115 |
|
Max.Grade muaj peev xwm Tsis muaj load / Puv |
% |
8/5 |
|
Nres daim ntawv |
|
Electromagnetic braking |
|
Tsav lub cev muaj zog |
kws |
2 |
|
Lifting lub cev muaj zog |
kws |
2.2 DC ua |
|
Hom roj teeb |
|
Lead acid roj teeb |
|
Roj teeb muaj peev xwm |
V/Ah |
24/210 |
|
Charger-ntse |
V/A |
24/30 |
|
Tsav tswj hom |
|
AC |
|
Tus tsav lub pob ntseg suab nrov raws li EN12053 |
dB (A) |
75 |
shipping npaj
Peb lub tuam txhab
LTMG Machinery txaus siab muab kev xaiv dav ntawm cov cuab yeej ua haujlwm hauv tsev rau khoom tsim los ua kom tau raws li kev xav tau ntawm ntau hom kev lag luam. Peb cov khoom lag luam nthuav dav suav nrog ntau yam kev daws teeb meem, xws li los ntawm ntau yam mus txog cov tsheb thauj khoom mus rau cov khoom siv pallet zoo thiab cov tsheb thauj khoom muaj zog, nrog rau lwm cov cuab yeej tseem ceeb. Nrog rau kev cog lus rau kev ua tau zoo, peb siv zog los muab kev lag luam nrog cov khoom lag luam txhim khu kev qha thiab thev naus laus zis zoo tshaj plaws los txhim kho lawv cov khoom lag luam.
FAQ
Q: Dab tsi yog qhov txiaj ntsig tseem ceeb ntawm kev siv Double Deep Reach system hauv tsev rau khoom?
Q: Ob chav Deep Reach tsheb txhim kho qhov chaw siv li cas piv rau cov kab ke racking?
QYam khoom twg LTMG tshwj xeeb hauv?
QPuas yog LTMG muab cov lus qhia?
Cim npe nrov: Tuam Tshoj ob chav siab ncav cuag forklift, Tuam Tshoj ob chav siab ncav cuag forklift manufacturers
